| Screen size |
10.1 inch |
5 inch |
7 inch |
| Native resolution |
1280 x 800 |
854 x 480 |
1280 x 800 |
| Brightness |
1200 cd/m² |
600 cd/m² |
1000 cd/m² |
| Panel type |
IPS |
IPS |
IPS |
| Touch screen |
Capacitive multi-touch, 7H hardness, glove and wet touch |
Capacitive multi-touch |
Capacitive multi-touch (glove / wet touch capable) |
|
| Dimensions |
277 x 185 x 31.6 mm |
Per datasheet / installation drawing |
207.4 x 137.4 x 30.1 mm |
| Weight |
1450 g |
Per configuration |
810 g |
| Industrial Ratings |
IP67, IK07, MIL-STD-810G (as certified configuration), ISO 7637-II |
Rugged vehicle-mount; ISO 7637-II transient protection |
IP67, 1.2 m drop, MIL-STD-810G (as certified configuration), ISO 7637-II |
|
| Video inputs |
USB 3.0 Type-C (DisplayPort Alt Mode, OTG) |
USB Type-C (DisplayPort Alt Mode, OTG) |
USB Type-C (DisplayPort Alt Mode, OTG) |
| Audio |
3.5 mm headset |
3.5 mm headset |
3.5 mm headset |
| Docking |
Docking port for RS232, CAN 2.0b (optional), RJ45, RS485, GPIO, video input (configuration dependent) |
— |
24-pin POGO connector |
| Micro SD |
Micro SD (up to 1TB) |
Micro SD slot |
Micro SD (up to 1TB) |
| SIM |
Nano SIM (optional eSIM) |
Micro SIM (optional, 4G LTE) |
Micro SIM |
| USB |
USB 3.0 Type-C (OTG) |
USB Type-C |
USB Type-C |
|
| 4G LTE |
— |
Optional LTE |
— |
| Bluetooth |
Bluetooth 5.0 LE |
Bluetooth 5.0 |
Bluetooth 5.0 LE |
| Cellular |
LTE / HSPA+ |
— |
4G LTE Cat4 |
| GNSS |
GPS, GLONASS, BDS, Galileo |
Optional GPS / multi-constellation |
GPS, GLONASS, BDS, Galileo |
| Wi-Fi |
Dual-band 2.4 GHz / 5 GHz |
802.11a/b/g/n/ac dual band |
802.11a/b/g/n/ac 2.4 GHz and 5 GHz |
|
| Battery |
8000 mAh Li-ion (user replaceable) |
— |
5000 mAh (typical) |
| Input voltage |
DC 8 to 36V |
DC 8 to 36V |
DC 8 to 36V |
| Power consumption |
≤18 W (typical, configuration dependent) |
≤12 W (typical, configuration dependent) |
≤15 W (typical, configuration dependent) |
|
| CPU |
Qualcomm octa-core (4×A73 2.0 GHz + 4×A53 1.8 GHz) |
Qualcomm Cortex-A53 64-bit quad-core up to 2.0 GHz |
Qualcomm octa-core (4×A73 2.0 GHz + 4×A53 1.8 GHz) |
| GPU |
Adreno 610 |
Adreno 702 |
Qualcomm Adreno (platform integrated) |
| Operating system |
Android 13 |
Android 12 |
Android 13 (GMS) |
| RAM |
4GB LPDDR4 (default) / 8GB (optional) |
3GB (default) / 4GB (optional) |
4GB LPDDR4 (default) / 8GB (optional) |
| Storage |
64GB UFS (default) / 128GB (optional) |
32GB (default) / 64GB (optional) |
64GB eMMC (default) / 128GB (optional) |
|
| Included |
Quick start / installation documentation |
Installation documentation |
Quick start / installation documentation |
| Optional |
Docking station, Vehicle mount hardware |
Vehicle mount kits, Breakout / docking cables (per BOM) |
Docking station, Vehicle mount hardware, NFC module (optional) |
|
| Operating temperature |
Per certified configuration |
-20°C to 65°C |
-10°C to 65°C |
| Storage temperature |
Per certified configuration |
-30°C to 70°C |
-20°C to 70°C |
|
| Front camera |
5MP (optional) |
— |
— |
| Rear camera |
16MP with LED (optional) |
— |
Optional (configuration dependent) |
