| Screen size |
9.7 inch |
8 inch |
7 inch |
10.1 inch |
9.7 inch |
7 inch |
7 inch |
| Native resolution |
1024 x 768 |
800 x 480 |
800 x 480 |
1024 x 600 |
1024 x 768 |
1280 x 800 |
800 x 480 |
| Aspect ratio |
4:3 |
4:3 |
16:9 |
16:10 |
4:3 |
16:10 |
16:10 |
| Brightness |
300 cd/m² |
250 cd/m² |
250 cd/m² |
250 cd/m² |
420 cd/m² |
1000 cd/m² |
1000 cd/m² |
| Contrast |
600:1 |
500:1 |
500:1 |
500:1 |
900:1 |
800:1 |
500:1 |
| LED lifetime |
— |
— |
— |
— |
— |
50,000 h |
— |
| Panel type |
LCD |
LCD |
LCD |
LCD |
LCD |
LCD |
LCD |
| Viewing angle |
178°/178° (H/V) |
140°/120° (H/V) |
140°/120° (H/V) |
140°/110° (H/V) |
160°/174° (H/V) |
170°/170° (H/V) |
140°/120° (H/V) |
|
| Touch screen (Optional) |
4-wire resistive (5-wire optional) |
4-wire resistive |
4-wire resistive |
4-wire resistive (5-wire optional) |
5-wire resistive |
10-point PCAP |
10-point capacitive |
|
| Video inputs |
1x HDMI 1.4, 1x Mini USB |
1x USB Type-A |
1x USB Type-A |
1x USB Type-A |
1x HDMI, 1x VGA, 2x Composite |
1x HDMI, 1x VGA |
1x HDMI 1.4b, 1x VGA, 2x Video (RCA) |
| Audio |
Built-in speakers x 2, 3.5 mm ear jack (2ch 48kHz 24-bit) |
— |
— |
— |
Built-in speaker x 1, 3.5 mm ear jack |
Built-in speaker x 1, HDMI audio, 3.5 mm ear jack (2ch 48kHz 24-bit) |
Built-in speaker x 1, HDMI 2ch, 3.5 mm ear jack (2ch 48kHz 24-bit), 3.5 mm audio input |
| Additional connections |
— |
— |
— |
— |
— |
— |
— |
|
| Composite |
— |
— |
— |
— |
1080p 24/25/30/50/60, 1080pSF 24/25/30, 1080i 50/60, 720p 50/60 |
— |
— |
| HDMI |
720p 50/60, 1080i 50/60, 1080p 24/25/30/50/60 |
— |
— |
— |
720p 50/60, 1080i 50/60, 1080p 50/60 |
2160p 24/25/30, 1080p 24/25/30/50/60, 1080i 50/60, 720p 50/60 |
2160p 24/25/30, 1080p 24/25/30/50/60, 1080i 50/60, 720p 50/60 |
| VGA |
— |
— |
— |
— |
1080p 24/25/30/50/60, 1080pSF 24/25/30, 1080i 50/60, 720p 50/60 |
1080p 24/25/30/50/60, 1080pSF 24/25/30, 1080i 50/60, 720p 50/60 |
1080p 24/25/30/50/60, 1080pSF 24/25/30, 1080i 50/60, 720p 50/60 |
|
| Input voltage |
DC 5V |
DC 5V (USB) |
DC 5V (USB) |
DC 5V |
DC 7 to 24V |
DC 9 to 36V |
DC 12 to 24V |
| Power consumption |
≤9 W |
≤4.5 W |
≤4.5 W |
≤6 W |
≤10 W |
≤8.5 W (12V) |
≤8.5 W (12V) |
|
| Dimensions |
242 x 195 x 15 mm |
200 x 156 x 25 mm |
188 x 123 x 25.8 mm |
253.5 x 162.5 x 34 mm (61 mm with bracket) |
234.4 x 192.5 x 29 mm |
184.5 x 118.8 x 32 mm |
210 x 131 x 34.2 mm |
| Weight |
675 g (without bracket) / 1175 g (with bracket) |
536 g |
385 g |
1004 g |
625 g |
410 g |
710 g |
|
| Included |
5V DC Adapter, HDMI A/C Cable, CD Driver, Car Power Adapter, Manual |
CD Driver, Manual |
CD Driver, Manual |
5V DC Adapter, CD Driver, Manual |
12V DC Adapter, Remote Control, HDMI A-C Cable, HDMI to DVI Cable, SKS Cable to VGA & RCA, CD Driver, Manual |
12V 2A Power Adapter, HDMI A-A Cable |
12V 2A Power Adapter, HDMI A-A Cable, VGA Cable, Audio Input Cable, AV Input Cable x 2, Fixed Screws x 4, Manual |
| Optional |
VESA Folding Bracket, VESA Rail Slot |
VESA Rail Slot, VESA Folding Bracket |
— |
VESA Rail Slot |
VESA Folding Bracket, VESA Rail Slot |
IP 65 Frame, Remote Control, VESA 75 mm Bracket, HDMI Cable Lock |
Remote Control, HDMI Cable Lock |
|
| Industrial Ratings |
— |
— |
— |
— |
— |
— |
IP64 front panel (IP6X dust, IPX4 water) |
| Operating temperature |
-20°C to 60°C |
-20°C to 60°C |
-20°C to 60°C |
-20°C to 60°C |
-20°C to 60°C |
-20°C to 60°C |
-20°C to 60°C |
| Storage temperature |
-30°C to 70°C |
-30°C to 70°C |
-30°C to 70°C |
-30°C to 70°C |
-30°C to 70°C |
-30°C to 80°C |
-30°C to 70°C |
|
| VESA mount |
VESA mount compatible |
VESA mount compatible |
— |
VESA mount compatible |
VESA mount compatible |
75 mm |
— |
| Wall mount |
— |
— |
— |
— |
— |
— |
4 slots |
